American Eagle

The symbol of RV excellence

Bus image

Since its inception, the American Eagle has provided the blueprint for all other coach models. It’s also consistently raised the bar for what it means to bring luxury into a motorcoach. The 2022 update continues this tradition, combining premium construction and detailing both under the hood and in the living quarters. When it comes to premium travel experiences, the 2022 American Eagle soars above the competition.

What makes the American Eagle a premium experience?

  • A world of power beneath your feet, including a Cummins ISX15 605 horsepower engine and an Allison 4000 Series six-speed transmission
  • Hitch your tow vehicle to the back without worry thanks to its 20,000-pound towing capacity
  • Manage all critical systems from your mobile device with Multiplex Controls
  • The most comfortable driver and passenger seats around, featuring heat and air-cool, 8-way power adjustment, lumbar support, and a power footrest
  • Multiple LED smart TVs throughout the living space

Chassis

Chassis Liberty Bridge Beam

FCCC SLM 605HP

GVWR

51000

GCWR

71000

Rear Axle GAWR

20000

Tag Axle GAWR

14000

Front Axle GAWR

17000

Hitch Rating

20000

Wheel Cut

56°

Front Suspension: ZF RL80EM IFS

S

Rear Suspension: V-Ride™ Air Suspension

S

Tag Suspension: UltraSteer® B-Series

S

Front Brakes: Bendix® Air Disc w/ABS

S

Rear Brakes: Bendix® Air Disc w/ABS

S

Shock Absorbers: SACHS® Custom-Tuned

S

Select Drive Steering

S

Valid Air Leveling

S

Radiator Configuration: Side

S

Remote Air Connection

S

Remote DEF Fill

S

Engine Brake: Compression Brake 3 Stage

S

Electric Alert Horn

S

Keyless Push Button Start

S

Automotive-Style Headlights

S

Front Tires

315/80R 22.5

Tag Tires

315/80R 22.5

Rear Tires

315/80R 22.5

Front and Rear Aluminum Wheels

S

Tire Pressure Monitoring System

S

Brake Sync

S

RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®

S

Engine Equipment

Cummins® ISX15 605HP 1950 lb./ft.

S

Alternator: 270 Amp

S

Allison® 4000 MH 6-Speed Automatic Transmission

S

Engine Block Heater

S

Chassis Battery: (2) 12V Maintenance Free 1900 CCA

S

Sizes

Wheelbase

317"

Exterior Length

44' 11"

Exterior Width

102"

Exterior Height

13' 1"

Interior Height

84"

Interior Width

96"

# of Slideouts

4

Capacities

Fuel (gal.)

150

Fresh Water (gal.)

105

Gray Waste Water (gal.)

75

Black Waste Water (gal.)

50

Def Tank (gal.)

15

Construction

Powerlock System: Interlocking Floor, Walls, and Roof

S

Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors

S

Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors

S

Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)

S

Quiet Insulated, Ducted A/C System

S

Full Pass Through Basement Storage w/Easy Clean Composite Compartments

S

Basement Storage Lighting

S

Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)

S

Liberty Platform Chassis Construction

S

Steel-Constructed Entry Step Box

S

Hydraulic and Electric Slideout System

S

4-Point Fully-Automatic Hydraulic Leveling Jacks

S

Powder-Coated Steel Frame Chassis Construction

S

Rotocast-Molded, Durable, and Low Maintenance Service Compartment

S

Full-Coverage Heavy-Duty Undercoating

S

CSA Build

O

Exterior

Aerodynamic Fiberglass Cap w/Automotive LED Head lighting

S

Rear Fiberglass Cap w/Rear Engine Access, Automotive-Style LED Lighting, and Grill

S

Power Rear Engine Door

S

Fiberglass Wheel Well Skirts

S

Molded-Fiberglass One-Piece Roof

S

Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract

S

2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract

S

Slideout Awning Toppers Above All Slideouts

S

Power Window Awning Package

S

Power Entry Door Awning w/LED Lights

S

Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks

S

Keyless Entry Door System

S

Chrome Luggage Door Handles

S

Power Luggage Door Locks (Select Doors)

S

Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry

S

Exterior Power Entry Step w/Light

S

Side-Swing Aluminum Bus-Style Luggage Doors

S

Large Dark-Tinted Frameless Windows

S

LED Patio Light(s)

S

Front, Side, and Rear LED Clearance and Marker Lighting

S

Gravity and City Fresh Water Fill

S

Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, and Drainage Valves

S

Hitch: 20,000 lb. Capacity w/7-Way Round Tow Connection

S

Winegard Autodome Digital TV Antenna

S

4-Point Fully-Automatic Hydraulic Leveling Jacks

S

Valid Air Leveling

S

Rear Ladder

O

Premier Full-Body Paint w/Front Clear Mask

S

Roof Vent Rain Covers

S

Winegard Trav'ler DISH® Network Satellite System

O

Winegard Trav'ler DIRECTV® Satellite System

O

Winegard In-Motion Satellite System

S

Undercarriage Lighting

S

Exterior Accent Lighting Under Slideout

S

Exterior Chrome Package (12")

S

Lower Storage Compartment Slide Tray

S

Power Lower Storage Compartment Slide Tray (1st Bay)

S

Power Lower Storage Compartment Slide Tray (2nd Bay)

O

Basement Freezer

O

Full-Length Rear Mudguard w/Stainless Accent

S

Emergency Exit Door

S

Cab Exterior

Automotive-Style One-Piece Windshield

S

Daytime Running Lights

S

Power Driver's Window

S

Fog Lamps

S

Top-Mounted Windshield Wiper System

S

Top-Mounted Remote Power and Heated Chrome Mirrors w/Turn Signals and Side Cameras

S

Cab Interior

LED OptiView™ Instrument Panel (FCCC)

S

High-Output Dash Air Conditioning and Heat

S

Air Suspension Deflation System

S

Electronic Cruise Control

S

Windshield Wipers w/Delay

S

Remote Switch for Power and Heated Mirrors

S

Driver Console w/Lower Storage Bin

S

TRW Column Drive w/Tilt and Telescopic Power Adjust

S

Driver Chair w/Heat and Air-Cool, 8-Way Power, Lumbar, and Power Footrest

S

Passenger Chair w/Heat and Air-Cool, 8-Way Power, Lumbar, and Power Footrest

S

Driver and Passenger ABS-Style Armrest

S

Driver and Passenger Cup Holders

S

Power Windshield Roller Shade/Blind

S

Driver and Passenger Window Power Roller Shades

S

Driver and Passenger Overhead Map Lighting

S

Adjustable Suspended Pedals

S

Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor

S

JBL® Premium Audio Sound System

S

Blind Spot Detection

S

360° Camera System

O

SiriusXM® Satellite Radio Ready (Requires Subscription)

S

USB and Auxiliary Inputs

S

Integrated 3-Point Driver and Passenger Seatbelts w/Adjustable Straps

S

Automotive-Style Wrap-Around Dash

S

Wireless Cell Phone Charging Pads at Driver and Passenger

S

12V Accessory Ports

S

110V A/C Outlets

S

Power Stepwell Cover

S

Generator On/Off Switch

S

Battery Booster Switch

S

Automatic Leveling Jacks Controls

S

Auxillary Start Switch

S

Interior

Loveseat

S

Sofa Sleeper w/Twin-Sized Mattress

O

Sofa Sleeper w/Queen-Sized Mattress

S

Theater Seating Sofa

O

Free-Standing Dinette w/Credenza/Computer Workstation

S

Quartz Tops Throughout

S

Interior Flat Soft-Touch Vinyl Ceiling

S

Porcelain Tile Flooring

S

Heated Tile Flooring

S

Ozite-Lined Cabinet Interiors

S

Cedar-Lined Wardrobe Interiors (Select Locations)

S

Full-Extension Drawer Guides Throughout w/Latches

S

Cabinet Doors w/Hidden Hinges

S

Hardwood Doors and Drawers

S

Hardwood Ceiling Treatment

S

Color-Coordinating Solid-Wood Fascia

S

Solid Wood Valances w/Fabric Wrapped Inserts

S

Power Day/Night Roller Shades

S

Energy Efficient 3" LED Flush-Mounted Ceiling and Under Cabinet Reading Lights Throughout

S

Interior Décor Choices

3

Wood Color Choices

4

Interior Entry

Battery Disconnect and Control Panel

S

Metal Interior Grab Handle at Entry

S

Solid-Surface Entry Step w/LED Accent Lighting

S

Kitchen

Residential 4-Door Refrigerator w/Ice and Water Dispenser

S - 23CF

2-Burner Recessed Induction Cooktop

S

Residential Over-the-Range Convection Microwave

S

Dishwasher

S

Tile or Solid-Surface Backsplash

S

Granite Composite Sink

S

Residential Faucet w/Pull-Out Sprayer

S

Adjustable Shelves Throughout

S

Full-Extension Drawer Guides w/Latches

S

Fan-Tastic® Power Vent w/Wall Switch

S

Wastebasket

S

Wastebasket

King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head

S

Designer Bedspread, Pillow Shams, and Pillows

S

Solid-Wood Valances w/Fabric-Wrapped Inserts

S

Quartz Nightstand Tops

S

Safe

S

Bathroom

Under-Mounted Porcelain Sink

S

Residential Faucet

S

Deluxe Wood Medicine Cabinet w/Mirror

S

Tile or Solid-Surface Backsplash

S

Tile Shower Surround

S

Glass Shower Door

S

Shower Skylight

S

Metal Shower Head w/Sliding Adjustable Bar, Soap Dish, and Matching Faucet

S

Towel Rings/Bars, Toliet Paper Holder, and Robe Hook

S

Tecma Porcelain Macerator Toilet

S

Fan-Tastic® Power Ceiling Vent

S

Entertainment

LED Smart TV (Bedroom)

S

LED Smart TV (Living Area, Televator)

S

LED Smart TV (Front Overhead)

O

HDMI/CAT6 Video Distribution and Wiring

S

Soundbar (Living Area)

S

Blu-Ray® DVD Player (Living Area)

S

Cable TV and HDMI Video Ready

S

WiFiRanger™ Sky Pro 4 w/LTE Pack Router

S

Exterior Entertainment Center: LED Smart TV, Swivel Mount, and Soundbar

S

Camera Switching to Living/Bedroom TV's

S

Electric & Utilities

Technology Package: WIFI Extender, Cell Booster, and 300W Solar Panel

O

High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump

S

Roof A/C Condensation Lines

S

Aqua Hot® 600D

S

Service: 50 Amp

S

Inverter: Single 2800W Pure Sine

S

Solar Panel: 100W

S

Multiplex Lighting

S

(8) 6V Auxillary AGM Batteries

S

Lithium Battery Upgrade

O

Neutral Loss Protection / EMS

S

Generator: 12.5kw Onan

S

Automatic Generator Start

S

Master Battery Disconnect Switch

S

12V 3GPM High-Capacity SHURflo® Water Pump

S

Water Filtration System (Whole Coach)

S

Macerator Holding Tank Dump System

S

UViaLite™ Waste Tank Purification System

S

Cable TV and Satellite Hook-Up

S

San-T-Flush™ Black Holding Tank Flush System

S

Single-Location Monitor Panel w/Touch Sensor Tank Monitoring

S

Fire Extinguisher, LP/CO and Smoke Detectors

S

Exterior GFCI Receptacle in Exterior Storage

S

Central Vacuum

S

Samsung® Stackable Washer and Dryer

S

Electric Power Cord Reel

S

Power Water Hose Reel

S

50 Amp Shoreline Power Cord

S

Chassis

Chassis Liberty Bridge Beam

"FCCC SLM 605HP"

GVWR

51,000

GCWR

71,000

Rear Axle GAWR

20,000

Tag Axle GAWR

14,000

Front Axle GAWR

17,000

Hitch Rating

20,000

Wheel Cut

56°

Front Suspension: ZF RL80EM IFS

S

Rear Suspension: V-Ride™ Air Suspension

S

Tag Suspension: UltraSteer® B-Series

S

Front Brakes: Bendix® Air Disc w/ABS

S

Rear Brakes: Bendix® Air Disc w/ABS

S

Shock Absorbers: SACHS® Custom-Tuned

S

Select Drive Steering

S

Valid Air Leveling

S

Radiator Configuration: Side

S

Remote Air Connection

S

Remote DEF Fill

S

Engine Brake: Compression Brake 3 Stage

S

Electric Alert Horn

S

Keyless Push Button Start

S

Automotive-Style Headlights

S

Front Tires

315/80R 22.5

Tag Tires

315/80R 22.5

Rear Tires

315/80R 22.5

Front and Rear Aluminum Wheels

S

Tire Pressure Monitoring System

S

Brake Sync

S

RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®

S

Engine Equipment

Cummins® ISX15 605HP 1950 lb./ft.

S

Alternator: 270 Amp

S

Allison® 4000 MH 6-Speed Automatic Transmission

S

Engine Block Heater

S

Chassis Battery: (2) 12V Maintenance Free 1900 CCA

S

Sizes

Wheelbase

317"

Exterior Length

44' 11"

Exterior Width

102"

Exterior Height

13' 1"

Interior Height

84"

Interior Width

96"

# of Slideouts

3

Capacities

Fuel (gal.)

150

Fresh Water (gal.)

105

Gray Waste Water (gal.)

75

Black Waste Water (gal.)

50

Def Tank (gal.)

15

Construction

Powerlock System: Interlocking Floor, Walls, and Roof

S

Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors

S

Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors

S

Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)

S

Quiet Insulated, Ducted A/C System

S

Full Pass Through Basement Storage w/Easy Clean Composite Compartments

S

Basement Storage Lighting

S

Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)

S

Liberty Platform Chassis Construction

S

Steel-Constructed Entry Step Box

S

Hydraulic and Electric Slideout System

S

4-Point Fully-Automatic Hydraulic Leveling Jacks

S

Powder-Coated Steel Frame Chassis Construction

S

Rotocast-Molded, Durable, and Low Maintenance Service Compartment

S

Full-Coverage Heavy-Duty Undercoating

S

CSA Build

O

Exterior

Aerodynamic Fiberglass Cap w/Automotive LED Head lighting

S

Rear Fiberglass Cap w/Rear Engine Access, Automotive-Style LED Lighting, and Grill

S

Power Rear Engine Door

S

Fiberglass Wheel Well Skirts

S

Molded-Fiberglass One-Piece Roof

S

Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract

S

2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract

S

Slideout Awning Toppers Above All Slideouts

S

Power Window Awning Package

S

Power Entry Door Awning w/LED Lights

S

Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks

S

Keyless Entry Door System

S

Chrome Luggage Door Handles

S

Power Luggage Door Locks (Select Doors)

S

Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry

S

Exterior Power Entry Step w/Light

S

Side-Swing Aluminum Bus-Style Luggage Doors

S

Large Dark-Tinted Frameless Windows

S

LED Patio Light(s)

S

Front, Side, and Rear LED Clearance and Marker Lighting

S

Gravity and City Fresh Water Fill

S

Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, and Drainage Valves

S

Hitch: 20,000 lb. Capacity w/7-Way Round Tow Connection

S

Winegard Autodome Digital TV Antenna

S

4-Point Fully-Automatic Hydraulic Leveling Jacks

S

Valid Air Leveling

S

Rear Ladder

O

Premier Full-Body Paint w/Front Clear Mask

S

Roof Vent Rain Covers

S

Winegard Trav'ler DISH® Network Satellite System

O

Winegard Trav'ler DIRECTV® Satellite System

O

Winegard In-Motion Satellite System

S

Undercarriage Lighting

S

Exterior Accent Lighting Under Slideout

S

Exterior Chrome Package (12")

S

Lower Storage Compartment Slide Tray

S

Power Lower Storage Compartment Slide Tray (1st Bay)

S

Power Lower Storage Compartment Slide Tray (2nd Bay)

O

Basement Freezer

O

Full-Length Rear Mudguard w/Stainless Accent

S

Emergency Exit Door

S

Cab Exterior

Automotive-Style One-Piece Windshield

S

Daytime Running Lights

S

Power Driver's Window

S

Fog Lamps

S

Top-Mounted Windshield Wiper System

S

Top-Mounted Remote Power and Heated Chrome Mirrors w/Turn Signals and Side Cameras

S

Cab Interior

LED OptiView™ Instrument Panel (FCCC)

S

High-Output Dash Air Conditioning and Heat

S

Air Suspension Deflation System

S

Electronic Cruise Control

S

Windshield Wipers w/Delay

S

Remote Switch for Power and Heated Mirrors

S

Driver Console w/Lower Storage Bin

S

TRW Column Drive w/Tilt and Telescopic Power Adjust

S

Driver Chair w/Heat and Air-Cool, 8-Way Power, Lumbar, and Power Footrest

S

Passenger Chair w/Heat and Air-Cool, 8-Way Power, Lumbar, and Power Footrest

S

Driver and Passenger ABS-Style Armrest

S

Driver and Passenger Cup Holders

S

Power Windshield Roller Shade/Blind

S

Driver and Passenger Window Power Roller Shades

S

Driver and Passenger Overhead Map Lighting

S

Adjustable Suspended Pedals

S

Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor

S

JBL® Premium Audio Sound System

S

Blind Spot Detection

S

360° Camera System

O

SiriusXM® Satellite Radio Ready (Requires Subscription)

S

USB and Auxiliary Inputs

S

Integrated 3-Point Driver and Passenger Seatbelts w/Adjustable Straps

S

Automotive-Style Wrap-Around Dash

S

Wireless Cell Phone Charging Pads at Driver and Passenger

S

12V Accessory Ports

S

110V A/C Outlets

S

Power Stepwell Cover

S

Generator On/Off Switch

S

Battery Booster Switch

S

Automatic Leveling Jacks Controls

S

Auxillary Start Switch

S

Interior

Loveseat

S

Sofa Sleeper w/Full-Sized Mattress

O

Sofa Sleeper w/Queen-Sized Mattress

S

Theater Seating Sofa

O

Free-Standing Dinette w/Credenza/Computer Workstation

S

Quartz Tops Throughout

S

Electric Fireplace (Bedroom)

O

Interior Flat Soft-Touch Vinyl Ceiling

S

Porcelain Tile Flooring

S

Heated Tile Flooring

S

Ozite-Lined Cabinet Interiors

S

Cedar-Lined Wardrobe Interiors (Select Locations)

S

Full-Extension Drawer Guides Throughout w/Latches

S

Cabinet Doors w/Hidden Hinges

S

Hardwood Doors and Drawers

S

Hardwood Ceiling Treatment

S

Color-Coordinating Solid-Wood Fascia

S

Solid Wood Valances w/Fabric Wrapped Inserts

S

Power Day/Night Roller Shades

S

Energy Efficient 3" LED Flush-Mounted Ceiling and Under Cabinet Reading Lights Throughout

S

Interior Décor Choices

3

Wood Color Choices

4

Interior Entry

Battery Disconnect and Control Panel

S

Metal Interior Grab Handle at Entry

S

Solid-Surface Entry Step w/LED Accent Lighting

S

Kitchen

Residential 4-Door Refrigerator w/Ice and Water Dispenser

S - 23CF

2-Burner Recessed Induction Cooktop

S

Residential Over-the-Range Convection Microwave

S

Dishwasher

S

Tile or Solid-Surface Backsplash

S

Granite Composite Sink

S

Residential Faucet w/Pull-Out Sprayer

S

Adjustable Shelves Throughout

S

Full-Extension Drawer Guides w/Latches

S

Fan-Tastic® Power Vent w/Wall Switch

S

Wastebasket

S

Wastebasket

King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head

S

Designer Bedspread, Pillow Shams, and Pillows

S

Solid-Wood Valances w/Fabric-Wrapped Inserts

S

Quartz Nightstand Tops

S

Safe

S

Bathroom

Under-Mounted Porcelain Sink

S

Residential Faucet

S

Deluxe Wood Medicine Cabinet w/Mirror

S

Tile or Solid-Surface Backsplash

S

Tile Shower Surround

S

Glass Shower Door

S

Shower Skylight

S

Metal Shower Head w/Sliding Adjustable Bar, Soap Dish, and Matching Faucet

S

Towel Rings/Bars, Toliet Paper Holder, and Robe Hook

S

Tecma Porcelain Macerator Toilet

S

Fan-Tastic® Power Ceiling Vent

S

Entertainment

LED Smart TV (Bedroom)

S

LED Smart TV (Living Area, Televator)

S

LED Smart TV (Front Overhead)

O

HDMI/CAT6 Video Distribution and Wiring

S

Soundbar (Living Area)

S

Blu-Ray® DVD Player (Living Area)

S

Cable TV and HDMI Video Ready

S

WiFiRanger™ Sky Pro 4 w/LTE Pack Router

S

Exterior Entertainment Center: LED Smart TV, Swivel Mount, and Soundbar

S

Camera Switching to Living/Bedroom TV's

S

Electric & Utilities

Technology Package: WIFI Extender, Cell Booster, and 300W Solar Panel

O

High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump

S

Roof A/C Condensation Lines

S

Aqua Hot® 600D

S

Service: 50 Amp

S

Inverter: Single 2800W Pure Sine

S

Solar Panel: 100W

S

Multiplex Lighting

S

(8) 6V Auxillary AGM Batteries

S

Lithium Battery Upgrade

O

Neutral Loss Protection / EMS

S

Generator: 12.5kw Onan

S

Automatic Generator Start

S

Master Battery Disconnect Switch

S

12V 3GPM High-Capacity SHURflo® Water Pump

S

Water Filtration System (Whole Coach)

S

Macerator Holding Tank Dump System

S

UViaLite™ Waste Tank Purification System

S

Cable TV and Satellite Hook-Up

S

San-T-Flush™ Black Holding Tank Flush System

S

Single-Location Monitor Panel w/Touch Sensor Tank Monitoring

S

Fire Extinguisher, LP/CO and Smoke Detectors

S

Exterior GFCI Receptacle in Exterior Storage

S

Central Vacuum

S

Samsung® Stackable Washer and Dryer

S

Electric Power Cord Reel

S

Power Water Hose Reel

S

50 Amp Shoreline Power Cord

S

Go to Top
