Indulge in perfection.
This country runs on the simple principle that with hard work you can create for yourself the best life possible. The 2022 update of our American Dream embodies that— it’s a hard-working luxury coach decked out with everything you need to live your best life. We added luxurious elements both under the hood and inside the cabin, giving you a powerful, reliable, and—most important of all—enjoyable experience every time you travel. No hard times. Only good times. Spoil yourself with the 2022 American Dream. You earned it.
What makes the American Dream a premium luxury travel experience?
Chassis: Liberty Bridge Beam
FREIGHTLINER ISL 450HP
GVWR
47,000
GCWR
62,000
Rear Axle GAWR
20,000
Front Axle GAWR
17,000
Tag Axle GAWR UltraSteer® B-Series
10,000
Hitch Rating
15,000
Front Suspension: ZF RL80EM IFS Air
S
Wheel Cut
56°
Rear Suspension: V-Ride™ Air Suspension
S
Front Brakes: Bendix® Air Disc w/ABS
S
Rear Brakes: Meritor® Drum w/ABS
S
Shock Absorbers: SACHS® Custom-Tuned
S
Select Drive Steering
S
Roll Stability Control
S
Valid Air Leveling
S
Radiator Configuration: Side
S
Remote Air Connection
S
Engine Brake: Compression Brake 3 Stage
S
Electric Alert Horn
S
Keyless Push Button Start
S
Automotive-Style Headlights
S
Front Tires
315/80R 22.5L
Rear Tires
315/80R 22.5L
Tag Tires
315/80R 22.5L
Front and Rear Aluminum Wheels
S
Tire Pressure Monitoring System
S
Brake Sync
S
RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®
S
Cummins® ISL Turbocharged 450 HP w/1250 lb./ft. Torque
S
Engine Braking: Jacobs® Compression
S
170 Amp Alternator
S
Allison® 3000 MH 6-Speed Automatic Transmission w/Electronic Shift Control
S
Engine Block Heater
S
Chassis Batteries: (2) 12V Maintenance 1900CCA
S
Wheelbase
267
Exterior Length
39'-9"
Exterior Width
102"
Exterior Height
13' 1"
Interior Height
84"
Interior Width
96"
# of Slideouts
4
Fuel (gal.)
150
Fresh Water (gal.)
105
Gray Waste Water (gal.)
75
Black Waste Water (gal.)
50
Def Tank (gal.)
13
Powerlock System: Interlocking Floor, Walls, and Roof
S
Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors
S
Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors
S
Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
S
Quiet Insulated, Ducted A/C System
S
Full Pass-Through Basement Storage w/Composite Floor, Wall Construction, and Lighting
S
Basement Storage Lighting w/Master Switch Inside Entry
S
Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)
S
Liberty Bridge Chassis Construction
S
Steel-Constructed Entry Step Box
S
Hydraulic and Electric Slideout Systems
S
4-Point Fully-Automatic Hydraulic Leveling Jacks
S
Powder-Coated Steel Frame Chassis Construction
S
Rotocast-Molded, Durable, and Low Maintenance Service Compartment
S
Full-Coverage Heavy-Duty Undercoating
S
CSA Build
O
Aerodynamic Fiberglass Cap w/Automotive-Style LED Headlighting
S
Rear Fiberglass Cap w/Fiberglass Rear Engine Access, Automotive LED Lighting and Grill
S
Fiberglass Wheel Well Trims
S
Molded-Fiberglass One-Piece Cap
S
4-Color Premier Full-Body Paint w/Front Clear Mask
4
Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
S
2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
O
Slideout Awning Toppers Above All Slideouts
S
Window Awning Package
S
Power Entry Door Awning w/LED Lights
S
Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks
S
Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry
S
Exterior Power Entry Step w/Light
S
Side-Swing Aluminum Bus-Style Baggage Doors
S
Power Luggage Door Locks (Select Doors)
S
Exterior Luggage Door stainless package (8")
S
Chrome Luggage Door Handles
S
Large Dark-Tinted Frameless Windows
S
LED Patio Light
S
Front, Side, and Rear LED Clearance and Marker Lighting
S
Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, Towel Holder, and Drainage Valves
S
Exterior Park Cable and Satellite Hook- Up
S
Hitch: 15,000 lb. Capacity w/7-Way Round Tow Connection
S
Winegard 360° TV Antenna
S
Battery Disconnect
S
Rear Ladder
S
Winegard In-Motion Satellite System
O
Winegard Trav'ler DISH® Network Satellite System
O
Winegard Trav'ler DIRECTV® Satellite System
O
Roof Vent Rain Covers
S
1st Bay 90" Tray Package
O
1st Bay 36"/54" Tray Package
O
Exterior Freezer
O
Undercarriage Lighting
S
Exterior Accent Lighting Under Slideout
S
Full-Length Rear Mudguard w/Stainless Accent
S
Emergency Exit Door
S
Automotive-Style One-Piece Windshield
S
Daytime Running Lights
S
Top Mount Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome
S
Tinted Driver Window Power
S
Tinted Frameless Passenger Window
S
Fog Lamps
S
Top-Mounted Windshield Wiper System
S
LED OptiView™ Instrument Panel (FCCC)
S
High-Output Dash Air Conditioning and Heat
S
Air Suspension Deflation System
S
Electronic Cruise Control
S
Windshield Wipers w/Delay
S
Remote Switch for Power and Heated Mirrors
S
Steering Wheel w/Tilt and Telescoping Column
S
Driver Console w/Lower Storage Bin
S
Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor
S
SiriusXM® Satellite Radio Ready (Requires Subscription)
S
JBL® Premium Audio Sound System (Technology Package)
O
Blind Spot Detection
S
USB and Auxiliary Inputs
S
Wireless Cell Phone Charging Pads at Driver and Passenger
S
Driver Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Passenger Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Integrated Driver and Passenger Seat Belts w/Adjustable Straps
S
12V Accessory Ports
S
110V A/C Outlet at Dash Area
S
Automotive-Style Wrap-Around Dash
S
Passenger Armrest
S
Passenger Monitor - 7" Color
O
Driver and Passenger Cup Holders
S
Front Power Roller Shade/Blind
S
Driver and Passenger Entry Door Power Shade/Blind
S
Adjustable Suspended Pedals
S
Power Stepwell Cover
S
Cab Lights
S
Generator On/Off Switch
S
Auxillary Start Switch
S
Loveseat
O
Sofa Sleeper w/Full-Sized Mattress
S
Theater Seating Sofa w/Power Footrest
S
Duel Euro Recliners w/Table
O
Free-Standing Dinette
S
Interior Flat Soft-Touch Vinyl Ceiling
S
Porcelain Tile Flooring
S
Full-Extension Drawer Guides Throughout w/Latches
S
Cabinet Doors w/Hidden Hinges
S
Hardwood Doors and Drawers
S
Color Coordinating Solid Wood Fascia
S
Solid Wood Valances w/Fabric Wrapped Inserts
S
Power Day/Night Roller Shades
S
Energy Efficient LED 3" Puck Flush Mount Ceiling and Under Cabinet Lighting
S
Solid Surface Entry Step w/LED Accent Lighting
S
Battery disconnect and Control Panel
S
Metal Interior Grab Handle at Entry
S
Residential 4-Door Refrigerator w/Ice and Water Dispenser
S
2-Burner Recessed Induction Cooktop
S
Residential Over-the-Range Convection Microwave
S
Dishwasher
O
Quartz Countertop
S
Tile Backsplash
S
Stainless Steel Sink w/Colander, Cutting Board, and Drying Rack
S
Residential Faucet w/Pull-Out Sprayer
S
Adjustable Shelves Throughout Kitchen
S
Full-Extension Drawer Guides w/Latches
S
Fan-Tastic® Power Vent w/Wall Switch
S
Wastebasket
S
Wine Cooler
S
King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head
S
Designer Bedspread, Pillow Shams, and Pillows
S
Solid-Wood Valances w/Fabric-Wrapped Inserts
S
Quartz Nightstand Tops
S
Safe
S
Quartz Bathroom Countertop
S
Tile Backsplash
S
Residential Faucet
S
Deluxe Hardwood Medicine Cabinet w/Mirror
S
Tile Shower Enclosure
S
Glass Shower Door
S
Shower Skylight
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Faucet
S
TECMA® Porcelain Macerator Toilet
S
Fan-Tastic® Power Vent w/Wall Switch
S
Towel Rings
S
LED Smart TV (Bedroom)
S
LED Smart TV (Living Area, Televator)
S
LED Smart TV (Front Overhead)
O
HDMI/CAT5 Video Distribution and Wiring
S
Camera Switching to Living/Bedroom TVs
S
Blu-Ray® Player w/WIFI
S
JBL® Soundbar
S
Exterior Entertainment Center: LED Smart TV and JBL® Soundbar
S
Technology Package: WiFi Extender, Cell Booster, 300W Solar Panel, JBL® Premium Audio System, WiFiRanger™
O
High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump
S
Roof A/C Condensation Lines
S
Aqua Hot® 450D
S
Service: 50 Amp
S
Converter: 125 Amp Power Converter
S
Inverter: Single 2800W Pure Sine
S
Neutral Loss Protection
S
Generator: 12.5kw Onan Quiet Diesel
S
Automatic Generator Start
S
6V Auxillary AGM Batteries
S
Battery Upgrade Package: Lithium Batteries
O
Master Battery Disconnect Switch
S
Water Filtration System (Whole Coach)
S
Macerator Holding Tank Dump System
S
UViaLite™ Waste Tank Purification System
S
Electric Power Cord Reel
S
Power Water Hose Reel
S
50 Amp Shoreline Power Cord
S
Samsung® 220V Stackable Washer and Dryer
S
Central Vacuum
S
Cable TV and Satellite Hook-Up
S
Toliet Tank San-T-Flush™ System
S
Multiplex Wiring Control System w/Touch Screen and App Control
S
Carbon Monoxide and Smoke Detectors, Fire Extinguisher
S
Exterior GFCI Receptacle in Exterior Storage
S
100W Solar Panel
S
300W Solar Panel (Technology Package)
O
Cellular Booster (Technology Package)
O
Chassis: Liberty Bridge Beam
FREIGHTLINER ISL 450HP
GVWR
47,000
GCWR
62,000
Rear Axle GAWR
20,000
Front Axle GAWR
17,000
Tag Axle GAWR UltraSteer® B-Series
10,000
Hitch Rating
15,000
Front Suspension: ZF RL80EM IFS Air
S
Wheel Cut
56°
Rear Suspension: V-Ride™ Air Suspension
S
Front Brakes: Bendix® Air Disc w/ABS
S
Rear Brakes: Meritor® Drum w/ABS
S
Shock Absorbers: SACHS® Custom-Tuned
S
Select Drive Steering
S
Roll Stability Control
S
Valid Air Leveling
S
Radiator Configuration: Side
S
Remote Air Connection
S
Engine Brake: Compression Brake 3 Stage
S
Electric Alert Horn
S
Keyless Push Button Start
S
Automotive-Style Headlights
S
Front Tires
315/80R 22.5L
Rear Tires
315/80R 22.5L
Tag Tires
315/80R 22.5L
Front and Rear Aluminum Wheels
S
Tire Pressure Monitoring System
S
Brake Sync
S
RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®
S
Cummins® ISL Turbocharged 450 HP w/1250 lb./ft. Torque
S
Engine Braking: Jacobs® Compression
S
170 Amp Alternator
S
Allison® 3000 MH 6-Speed Automatic Transmission w/Electronic Shift Control
S
Engine Block Heater
S
Chassis Batteries: (2) 12V Maintenance 1900CCA
S
Wheelbase
302"
Exterior Length
42'-11"
Exterior Width
102"
Exterior Height
13' 1"
Interior Height
84"
Interior Width
96"
# of Slideouts
3
Fuel (gal.)
150
Fresh Water (gal.)
100
Gray Waste Water (gal.)
60
Black Waste Water (gal.)
40
Def Tank (gal.)
13
Powerlock System: Interlocking Floor, Walls, and Roof
S
Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors
S
Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors
S
Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
S
Quiet Insulated, Ducted A/C System
S
Full Pass-Through Basement Storage w/Composite Floor, Wall Construction, and Lighting
S
Basement Storage Lighting w/Master Switch Inside Entry
S
Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)
S
Liberty Bridge Chassis Construction
S
Steel-Constructed Entry Step Box
S
Hydraulic and Electric Slideout Systems
S
4-Point Fully-Automatic Hydraulic Leveling Jacks
S
Powder-Coated Steel Frame Chassis Construction
S
Rotocast-Molded, Durable, and Low Maintenance Service Compartment
S
Full-Coverage Heavy-Duty Undercoating
S
CSA Build
O
Aerodynamic Fiberglass Cap w/Automotive-Style LED Headlighting
S
Rear Fiberglass Cap w/Fiberglass Rear Engine Access, Automotive LED Lighting and Grill
S
Fiberglass Wheel Well Trims
S
Molded-Fiberglass One-Piece Cap
S
4-Color Premier Full-Body Paint w/Front Clear Mask
S
Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
S
2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
O
Slideout Awning Toppers Above All Slideouts
S
Window Awning Package
S
Power Entry Door Awning w/LED Lights
S
Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks
S
Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry
S
Exterior Power Entry Step w/Light
S
Side-Swing Aluminum Bus-Style Baggage Doors
S
Power Luggage Door Locks (Select Doors)
S
Exterior Luggage Door stainless package (8")
S
Chrome Luggage Door Handles
S
Large Dark-Tinted Frameless Windows
S
LED Patio Light
S
Front, Side, and Rear LED Clearance and Marker Lighting
S
Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, Towel Holder, and Drainage Valves
S
Exterior Park Cable and Satellite Hook- Up
S
Hitch: 15,000 lb. Capacity w/7-Way Round Tow Connection
S
Winegard 360° TV Antenna
S
Battery Disconnect
S
Rear Ladder
S
Winegard In-Motion Satellite System
O
Winegard Trav'ler DISH® Network Satellite System
O
Winegard Trav'ler DIRECTV® Satellite System
O
Roof Vent Rain Covers
S
1st Bay 90" Tray Package
O
2nd Bay 90" Tray Package
O
2nd Bay 36"/54" Tray Package
O
Exterior Freezer
O
Undercarriage Lighting
S
Exterior Accent Lighting Under Slideout
S
Full-Length Rear Mudguard w/Stainless Accent
S
Emergency Exit Door
S
Automotive-Style One-Piece Windshield
S
Daytime Running Lights
S
Top Mount Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome
S
Tinted Driver Window Power
S
Tinted Frameless Passenger Window
S
Fog Lamps
S
Top-Mounted Windshield Wiper System
S
LED OptiView™ Instrument Panel (FCCC)
S
High-Output Dash Air Conditioning and Heat
S
Air Suspension Deflation System
S
Electronic Cruise Control
S
Windshield Wipers w/Delay
S
Remote Switch for Power and Heated Mirrors
S
Steering Wheel w/Tilt and Telescoping Column
S
Driver Console w/Lower Storage Bin
S
Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor
S
SiriusXM® Satellite Radio Ready (Requires Subscription)
S
JBL® Premium Audio Sound System (Technology Package)
O
Blind Spot Detection
S
USB and Auxiliary Inputs
S
Wireless Cell Phone Charging Pads at Driver and Passenger
S
Driver Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Passenger Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Integrated Driver and Passenger Seat Belts w/Adjustable Straps
S
12V Accessory Ports
S
110V A/C Outlet at Dash Area
S
Automotive-Style Wrap-Around Dash
S
Passenger Armrest
S
Passenger Monitor - 7" Color
O
Driver and Passenger Cup Holders
S
Front Power Roller Shade/Blind
S
Driver and Passenger Entry Door Power Shade/Blind
S
Adjustable Suspended Pedals
S
Power Stepwell Cover
S
Cab Lights
S
Generator On/Off Switch
S
Auxillary Start Switch
S
Loveseat
S
Sofa Sleeper w/Twin-Sized Mattress
O
Sofa Sleeper w/Full-Sized Mattress
S
Theater Seating Sofa w/Power Footrest
O
Free-Standing Dinette
S
Interior Flat Soft-Touch Vinyl Ceiling
S
Porcelain Tile Flooring
S
Full-Extension Drawer Guides Throughout w/Latches
S
Cabinet Doors w/Hidden Hinges
S
Hardwood Doors and Drawers
S
Color Coordinating Solid Wood Fascia
S
Solid Wood Valances w/Fabric Wrapped Inserts
S
Power Day/Night Roller Shades
S
Energy Efficient LED 3" Puck Flush Mount Ceiling and Under Cabinet Lighting
S
Interior Décor Choices
S
Wood Color Choices
S
Solid Surface Entry Step w/LED Accent Lighting
S
Battery disconnect and Control Panel
S
Metal Interior Grab Handle at Entry
S
Residential 4-Door Refrigerator w/Ice and Water Dispenser
S
2-Burner Recessed Induction Cooktop
S
Residential Over-the-Range Convection Microwave
S
Dishwasher
O
Quartz Countertop
S
Tile Backsplash
S
Stainless Steel Sink w/Colander, Cutting Board, and Drying Rack
S
Residential Faucet w/Pull-Out Sprayer
S
Adjustable Shelves Throughout Kitchen
S
Full-Extension Drawer Guides w/Latches
S
Fan-Tastic® Power Vent w/Wall Switch
S
Wastebasket
S
King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head
S
Designer Bedspread, Pillow Shams, and Pillows
S
Solid-Wood Valances w/Fabric-Wrapped Inserts
S
Quartz Nightstand Tops
S
Safe
S
Quartz Bathroom Countertop
S
Tile Backsplash
S
Residential Faucet
S
Deluxe Hardwood Medicine Cabinet w/Mirror
S
Tile Shower Enclosure
S
Glass Shower Door
S
Shower Skylight
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Faucet
S
TECMA® Porcelain Macerator Toilet
S
Fan-Tastic® Power Vent w/Wall Switch
S
Towel Rings
S
LED Smart TV (Bedroom)
S
LED Smart TV (Living Area, Televator)
S
LED Smart TV (Front Overhead)
O
HDMI/CAT5 Video Distribution and Wiring
S
Camera Switching to Living/Bedroom TVs
S
Blu-Ray® Player w/WIFI
S
JBL® Soundbar
S
Exterior Entertainment Center: LED Smart TV and JBL® Soundbar
S
Technology Package: WiFi Extender, Cell Booster, 300W Solar Panel, JBL® Premium Audio System, WiFiRanger™
O
High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump
S
Roof A/C Condensation Lines
S
Aqua Hot® 450D
S
Service: 50 Amp
S
Converter: 125 Amp Power Converter
S
Inverter: Single 2800W Pure Sine
S
Neutral Loss Protection
S
Generator: 12.5kw Onan Quiet Diesel
S
Automatic Generator Start
S
6V Auxillary AGM Batteries
S
Battery Upgrade Package: Lithium Batteries
O
Master Battery Disconnect Switch
S
Water Filtration System (Whole Coach)
S
Macerator Holding Tank Dump System
S
UViaLite™ Waste Tank Purification System
S
Electric Power Cord Reel
S
Power Water Hose Reel
S
50 Amp Shoreline Power Cord
S
Samsung® 220V Stackable Washer and Dryer
S
Central Vacuum
S
Cable TV and Satellite Hook-Up
S
Toliet Tank San-T-Flush™ System
S
Multiplex Wiring Control System w/Touch Screen and App Control
S
Carbon Monoxide and Smoke Detectors, Fire Extinguisher
S
Exterior GFCI Receptacle in Exterior Storage
S
100W Solar Panel
S
300W Solar Panel (Technology Package)
O
Cellular Booster (Technology Package)
O
Chassis: Liberty Bridge Beam
FREIGHTLINER ISL 450HP
GVWR
47,000
GCWR
62,000
Rear Axle GAWR
20,000
Front Axle GAWR
17,000
Tag Axle GAWR UltraSteer® B-Series
10,000
Hitch Rating
15,000
Front Suspension: ZF RL80EM IFS Air
S
Wheel Cut
56°
Rear Suspension: V-Ride™ Air Suspension
S
Front Brakes: Bendix® Air Disc w/ABS
S
Rear Brakes: Meritor® Drum w/ABS
S
Shock Absorbers: SACHS® Custom-Tuned
S
Select Drive Steering
S
Roll Stability Control
S
Valid Air Leveling
S
Radiator Configuration: Side
S
Remote Air Connection
S
Engine Brake: Compression Brake 3 Stage
S
Electric Alert Horn
S
Keyless Push Button Start
S
Automotive-Style Headlights
S
Front Tires
315/80R 22.5L
Rear Tires
315/80R 22.5L
Tag Tires
315/80R 22.5L
Front and Rear Aluminum Wheels
S
Tire Pressure Monitoring System
S
Brake Sync
S
RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®
S
Cummins® ISL Turbocharged 450 HP w/1250 lb./ft. Torque
S
Engine Braking: Jacobs® Compression
S
170 Amp Alternator
S
Allison® 3000 MH 6-Speed Automatic Transmission w/Electronic Shift Control
S
Engine Block Heater
S
Chassis Batteries: (2) 12V Maintenance 1900CCA
S
Wheelbase
302"
Exterior Length
42'-11"
Exterior Width
102"
Exterior Height
13' 1"
Interior Height
84"
Interior Width
96"
# of Slideouts
4
Fuel (gal.)
150
Fresh Water (gal.)
100
Gray Waste Water (gal.)
60
Black Waste Water (gal.)
40
Def Tank (gal.)
13
Powerlock System: Interlocking Floor, Walls, and Roof
S
Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors
S
Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors
S
Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
S
Quiet Insulated, Ducted A/C System
S
Full Pass-Through Basement Storage w/Composite Floor, Wall Construction, and Lighting
S
Basement Storage Lighting w/Master Switch Inside Entry
S
Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)
S
Liberty Bridge Chassis Construction
S
Steel-Constructed Entry Step Box
S
Hydraulic and Electric Slideout Systems
S
4-Point Fully-Automatic Hydraulic Leveling Jacks
S
Powder-Coated Steel Frame Chassis Construction
S
Rotocast-Molded, Durable, and Low Maintenance Service Compartment
S
Full-Coverage Heavy-Duty Undercoating
S
CSA Build
O
Aerodynamic Fiberglass Cap w/Automotive-Style LED Headlighting
S
Rear Fiberglass Cap w/Fiberglass Rear Engine Access, Automotive LED Lighting and Grill
S
Fiberglass Wheel Well Trims
S
Molded-Fiberglass One-Piece Cap
S
4-Color Premier Full-Body Paint w/Front Clear Mask
4
Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
S
2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
O
Slideout Awning Toppers Above All Slideouts
S
Window Awning Package
S
Power Entry Door Awning w/LED Lights
S
Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks
S
Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry
S
Exterior Power Entry Step w/Light
S
Side-Swing Aluminum Bus-Style Baggage Doors
S
Power Luggage Door Locks (Select Doors)
S
Exterior Luggage Door stainless package (8")
S
Chrome Luggage Door Handles
S
Large Dark-Tinted Frameless Windows
S
LED Patio Light
S
Front, Side, and Rear LED Clearance and Marker Lighting
S
Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, Towel Holder, and Drainage Valves
S
Exterior Park Cable and Satellite Hook- Up
S
Hitch: 15,000 lb. Capacity w/7-Way Round Tow Connection
S
Winegard 360° TV Antenna
S
Battery Disconnect
S
Rear Ladder
S
Winegard In-Motion Satellite System
O
Winegard Trav'ler DISH® Network Satellite System
O
Winegard Trav'ler DIRECTV® Satellite System
O
Roof Vent Rain Covers
S
1st Bay 90" Tray Package
O
2nd Bay 90" Tray Package
O
2nd Bay 36"/54" Tray Package
O
Exterior Freezer
O
Undercarriage Lighting
S
Exterior Accent Lighting Under Slideout
S
Full-Length Rear Mudguard w/Stainless Accent
S
Emergency Exit Door
S
Automotive-Style One-Piece Windshield
S
Daytime Running Lights
S
Top Mount Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome
S
Tinted Driver Window Power
S
Tinted Frameless Passenger Window
S
Fog Lamps
S
Top-Mounted Windshield Wiper System
S
LED OptiView™ Instrument Panel (FCCC)
S
High-Output Dash Air Conditioning and Heat
S
Air Suspension Deflation System
S
Electronic Cruise Control
S
Windshield Wipers w/Delay
S
Remote Switch for Power and Heated Mirrors
S
Steering Wheel w/Tilt and Telescoping Column
S
Driver Console w/Lower Storage Bin
S
Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor
S
SiriusXM® Satellite Radio Ready (Requires Subscription)
S
JBL® Premium Audio Sound System (Technology Package)
O
Blind Spot Detection
S
USB and Auxiliary Inputs
S
Wireless Cell Phone Charging Pads at Driver and Passenger
S
Driver Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Passenger Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Passenger Monitor - 7" Color
O
Integrated Driver and Passenger Seat Belts w/Adjustable Straps
S
12V Accessory Ports
S
110V A/C Outlet at Dash Area
S
Automotive-Style Wrap-Around Dash
S
Passenger Armrest
S
Driver and Passenger Cup Holders
S
Front Power Roller Shade/Blind
S
Driver and Passenger Entry Door Power Shade/Blind
S
Adjustable Suspended Pedals
S
Power Stepwell Cover
S
Cab Lights
S
Generator On/Off Switch
S
Auxillary Start Switch
S
Loveseat
S
Sofa Sleeper w/Full-Sized Mattress
S
Theater Seating Sofa w/Power Footrest
O
Free-Standing Dinette
S
Interior Flat Soft-Touch Vinyl Ceiling
S
Porcelain Tile Flooring
S
Full-Extension Drawer Guides Throughout w/Latches
S
Cabinet Doors w/Hidden Hinges
S
Hardwood Doors and Drawers
S
Color Coordinating Solid Wood Fascia
S
Solid Wood Valances w/Fabric Wrapped Inserts
S
Power Day/Night Roller Shades
S
Energy Efficient LED 3" Puck Flush Mount Ceiling and Under Cabinet Lighting
S
Solid Surface Entry Step w/LED Accent Lighting
S
Battery disconnect and Control Panel
S
Metal Interior Grab Handle at Entry
S
Residential 4-Door Refrigerator w/Ice and Water Dispenser
S
2-Burner Recessed Induction Cooktop
S
Residential Over-the-Range Convection Microwave
S
Dishwasher
O
Quartz Countertop
S
Tile Backsplash
S
Stainless Steel Sink w/Colander, Cutting Board, and Drying Rack
S
Residential Faucet w/Pull-Out Sprayer
S
Adjustable Shelves Throughout Kitchen
S
Full-Extension Drawer Guides w/Latches
S
Fan-Tastic® Power Vent w/Wall Switch
S
Wastebasket
S
King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head
S
Designer Bedspread, Pillow Shams, and Pillows
S
Solid-Wood Valances w/Fabric-Wrapped Inserts
S
Quartz Nightstand Tops
S
Safe
S
Quartz Bathroom Countertop
S
Tile Backsplash
S
Residential Faucet
S
Deluxe Hardwood Medicine Cabinet w/Mirror
S
Tile Shower Enclosure
S
Glass Shower Door
S
Shower Skylight
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Faucet
S
TECMA® Porcelain Macerator Toilet
S
Fan-Tastic® Power Vent w/Wall Switch
S
Towel Rings
S
LED Smart TV (Bedroom)
S
LED Smart TV (Living Area, Televator)
S
LED Smart TV (Front Overhead)
O
HDMI/CAT5 Video Distribution and Wiring
S
Camera Switching to Living/Bedroom TVs
S
Blu-Ray® Player w/WIFI
S
JBL® Soundbar
S
Exterior Entertainment Center: LED Smart TV and JBL® Soundbar
S
Technology Package: WiFi Extender, Cell Booster, 300W Solar Panel, JBL® Premium Audio System, WiFiRanger™
O
High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump
S
Roof A/C Condensation Lines
S
Aqua Hot® 450D
S
Service: 50 Amp
S
Converter: 125 Amp Power Converter
S
Inverter: Single 2800W Pure Sine
S
Neutral Loss Protection
S
Generator: 12.5kw Onan Quiet Diesel
S
Automatic Generator Start
S
6V Auxillary AGM Batteries
S
Battery Upgrade Package: Lithium Batteries
O
Master Battery Disconnect Switch
S
Water Filtration System (Whole Coach)
S
Macerator Holding Tank Dump System
S
UViaLite™ Waste Tank Purification System
S
Electric Power Cord Reel
S
Power Water Hose Reel
S
50 Amp Shoreline Power Cord
S
Samsung® 220V Stackable Washer and Dryer
S
Central Vacuum
S
Cable TV and Satellite Hook-Up
S
Toliet Tank San-T-Flush™ System
S
Multiplex Wiring Control System w/Touch Screen and App Control
S
Carbon Monoxide and Smoke Detectors, Fire Extinguisher
S
Exterior GFCI Receptacle in Exterior Storage
S
100W Solar Panel
S
300W Solar Panel (Technology Package)
O
Cellular Booster (Technology Package)
O
Chassis: Liberty Bridge Beam
FREIGHTLINER ISL 605HP
GVWR
51,000
GCWR
71,000
Rear Axle GAWR
20,000
Front Axle GAWR
17,000
Tag Axle GAWR UltraSteer® B-Series
14,000
Hitch Rating
20,000
Front Suspension: ZF RL80EM IFS Air
S
Wheel Cut
56°
Rear Suspension: V-Ride™ Air Suspension
S
Front Brakes: Bendix® Air Disc w/ABS
S
Rear Brakes: Bendix® Air Disc w/ABS
S
Shock Absorbers: SACHS® Custom-Tuned
S
Select Drive Steering
S
Roll Stability Control
S
Valid Air Leveling
S
Radiator Configuration: Side
S
Remote Air Connection
S
Remote DEF Fill
S
Engine Brake: Compression Brake 3 Stage
S
Electric Alert Horn
S
Keyless Push Button Start
S
Automotive-Style Headlights
S
Front Tires
315/80R 22.5L
Rear Tires
315/80R 22.5L
Tag Tires
315/80R 22.5L
Front and Rear Aluminum Wheels
S
Tire Pressure Monitoring System
S
Brake Sync
S
RoadWatch Safety System w/Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye®
S
Cummins® ISX Turbocharged 605 HP w/1950 lb./ft. Torque
S
Engine Braking: Jacobs® Compression
S
240 Amp Alternator
S
Allison 4000 MH 6-Speed Automatic transmission w/Electronic Shift Control
S
Engine Block Heater
S
Chassis Batteries: (2) 12V Maintenance 1900CCA
S
Wheelbase
319"
Exterior Length
44'-11"
Exterior Width
102"
Exterior Height
13' 1"
Interior Height
84"
Interior Width
96"
# of Slideouts
3
Fuel (gal.)
150
Fresh Water (gal.)
105
Gray Waste Water (gal.)
75
Black Waste Water (gal.)
50
Def Tank (gal.)
15
Powerlock System: Interlocking Floor, Walls, and Roof
S
Dryseal™ Edge Coating for all Sidewalls, Ceiling, and Floors
S
Vacu-Bond® Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors
S
Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
S
Quiet Insulated, Ducted A/C System
S
Full Pass-Through Basement Storage w/Composite Floor, Wall Construction, and Lighting
S
Basement Storage Lighting w/Master Switch Inside Entry
S
Heated Fresh Water and Holding Tank Compartments (w/Aqua Hot® Operational)
S
Liberty Bridge Chassis Construction
S
Steel-Constructed Entry Step Box
S
Hydraulic and Electric Slideout Systems
S
4-Point Fully-Automatic Hydraulic Leveling Jacks
S
Powder-Coated Steel Frame Chassis Construction
S
Rotocast-Molded, Durable, and Low Maintenance Service Compartment
S
Full-Coverage Heavy-Duty Undercoating
S
CSA Build
O
Aerodynamic Fiberglass Cap w/Automotive-Style LED Headlighting
S
Rear Fiberglass Cap w/Fiberglass Rear Engine Access, Automotive LED Lighting and Grill
S
Fiberglass Wheel Well Trims
S
Molded-Fiberglass One-Piece Cap
S
4-Color Premier Full-Body Paint w/Front Clear Mask
4
Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
S
2nd Roof-Mounted Electric Patio Awning w/LED Lighting and Motion Sensor Retract
O
Slideout Awning Toppers Above All Slideouts
S
Window Awning Package
S
Power Entry Door Awning w/LED Lights
S
Entry Door w/Screen Door, Latch, Deadbolt Lock, and Air Locks
S
Lighted Acrylic Grab Handle at Entry Door w/Keyless Entry
S
Exterior Power Entry Step w/Light
S
Side-Swing Aluminum Bus-Style Baggage Doors
S
Power Luggage Door Locks (Select Doors)
S
Exterior Luggage Door stainless package (8")
S
Chrome Luggage Door Handles
S
Large Dark-Tinted Frameless Windows
S
LED Patio Light
S
Front, Side, and Rear LED Clearance and Marker Lighting
S
Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, Towel Holder, and Drainage Valves
S
Exterior Park Cable and Satellite Hook- Up
S
Hitch: 20,000 lb. Capacity w/7-Way Round Tow Connection
S
Winegard 360° TV Antenna
S
Battery Disconnect
S
Rear Ladder
S
Winegard In-Motion Satellite System
O
Winegard Trav'ler DISH® Network Satellite System
O
Winegard Trav'ler DIRECTV® Satellite System
O
Roof Vent Rain Covers
S
1st Bay 90" Tray Package
O
2nd Bay 90" Tray Package
O
2nd Bay 36"/54" Tray Package
O
Exterior Freezer
O
Undercarriage Lighting
S
Exterior Accent Lighting Under Slideout
S
Full-Length Rear Mudguard w/Stainless Accent
S
Emergency Exit Door
S
Automotive-Style One-Piece Windshield
S
Daytime Running Lights
S
Top Mount Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome
S
Tinted Driver Window Power
S
Tinted Frameless Passenger Window
S
Fog Lamps
S
Top-Mounted Windshield Wiper System
S
LED OptiView™ Instrument Panel (FCCC)
S
High-Output Dash Air Conditioning and Heat
S
Air Suspension Deflation System
S
Electronic Cruise Control
S
Windshield Wipers w/Delay
S
Remote Switch for Power and Heated Mirrors
S
Steering Wheel w/Tilt and Telescoping Column
S
Driver Console w/Lower Storage Bin
S
Dash Radio: Dual 10" Touchscreen w/Bluetooth®, GPS Navigation, CD/DVD, SiriusXM® Radio Capability, and Back-Up Monitor
S
SiriusXM® Satellite Radio Ready (Requires Subscription)
S
JBL® Premium Audio Sound System (Technology Package)
O
Blind Spot Detection
S
USB and Auxiliary Inputs
S
Wireless Cell Phone Charging Pads at Driver and Passenger
S
Driver Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Passenger Chair w/Heat and Air-Cool, Reclining Back, Swivel, 6-way Power Controls, and Power Footrest
S
Integrated Driver and Passenger Seat Belts w/Adjustable Straps
S
12V Accessory Ports
S
110V A/C Outlet at Dash Area
S
Automotive-Style Wrap-Around Dash
S
Passenger Armrest
S
Passenger Monitor - 7" Color
O
Driver and Passenger Cup Holders
S
Front Power Roller Shade/Blind
S
Driver and Passenger Entry Door Power Shade/Blind
S
Adjustable Suspended Pedals
S
Power Stepwell Cover
S
Cab Lights
S
Generator On/Off Switch
S
Auxillary Start Switch
S
Jacknife Sofa
S
Sofa Sleeper w/Queen-Sized Mattress
S/O
Theater Seating Sofa w/Power Footrest
O
Free-Standing Dinette
S
Interior Flat Soft-Touch Vinyl Ceiling
S
Porcelain Tile Flooring
S
Full-Extension Drawer Guides Throughout w/Latches
S
Cabinet Doors w/Hidden Hinges
S
Hardwood Doors and Drawers
S
Color Coordinating Solid Wood Fascia
S
Solid Wood Valances w/Fabric Wrapped Inserts
S
Power Day/Night Roller Shades
S
Energy Efficient LED 3" Puck Flush Mount Ceiling and Under Cabinet Lighting
S
Solid Surface Entry Step w/LED Accent Lighting
S
Battery disconnect and Control Panel
S
Metal Interior Grab Handle at Entry
S
Residential 4-Door Refrigerator w/Ice and Water Dispenser
S
2-Burner Recessed Induction Cooktop
S
Residential Over-the-Range Convection Microwave
S
Dishwasher
O
Quartz Countertop
S
Tile Backsplash
S
Stainless Steel Sink w/Colander, Cutting Board, and Drying Rack
S
Residential Faucet w/Pull-Out Sprayer
S
Adjustable Shelves Throughout Kitchen
S
Full-Extension Drawer Guides w/Latches
S
Fan-Tastic® Power Vent w/Wall Switch
S
Wastebasket
S
King-Sized Encore® Series Memory Foam Mattress w/Adjustable Head
S
Designer Bedspread, Pillow Shams, and Pillows
S
Solid-Wood Valances w/Fabric-Wrapped Inserts
S
Quartz Nightstand Tops
S
Safe
S
Quartz Bathroom Countertop
S
Tile Backsplash
S
Residential Faucet
S
Deluxe Hardwood Medicine Cabinet w/Mirror
S
Tile Shower Enclosure
S
Glass Shower Door
S
Shower Skylight
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Faucet
S
TECMA® Porcelain Macerator Toilet
S
Fan-Tastic® Power Vent w/Wall Switch
S
Towel Rings
S
LED Smart TV (Bedroom)
S
LED Smart TV (Living Area, Televator)
S
LED Smart TV (Front Overhead)
O
HDMI/CAT5 Video Distribution and Wiring
S
Camera Switching to Living/Bedroom TVs
S
Blu-Ray® Player w/WIFI
S
JBL® Soundbar
S
Exterior Entertainment Center: LED Smart TV and JBL® Soundbar
S
Technology Package: WiFi Extender, Cell Booster, 300W Solar Panel, JBL® Premium Audio System, WiFiRanger™
O
High-Efficiency LoPro Ducted 15,000-BTU A/C Units w/Front and Rear Heat Pump
S
Roof A/C Condensation Lines
S
Aqua Hot® 450D
S
Service: 50 Amp
S
Converter: 125 Amp Power Converter
S
Inverter: Single 2800W Pure Sine
S
Neutral Loss Protection
S
Generator: 12.5kw Onan Quiet Diesel
S
Automatic Generator Start
S
6V Auxillary AGM Batteries
S
Battery Upgrade Package: Lithium Batteries
O
Master Battery Disconnect Switch
S
Water Filtration System (Whole Coach)
S
Macerator Holding Tank Dump System
S
UViaLite™ Waste Tank Purification System
S
Electric Power Cord Reel
S
Power Water Hose Reel
S
50 Amp Shoreline Power Cord
S
Samsung® 220V Stackable Washer and Dryer
S
Central Vacuum
S
Cable TV and Satellite Hook-Up
S
Toliet Tank San-T-Flush™ System
S
Multiplex Wiring Control System w/Touch Screen and App Control
S
Carbon Monoxide and Smoke Detectors, Fire Extinguisher
S
Exterior GFCI Receptacle in Exterior Storage
S
100W Solar Panel
S
300W Solar Panel (Technology Package)
O
Cellular Booster (Technology Package)
O
© 2024 REV Group, INC. All Rights Reserved
